Home / Products / PVC Power Cable - Type 1 Cable

1

Conductor

<10mm2:  Stranded conductor in especially bending -resistance version consisting of bare copper Wires (following EN60228)

10mm2 : conductor cable consisting of pre-leads

2

Core Insulation

 Mechanically high-quality, especially low-capacitance TPE mixture.

3

Core Stranding

Core Stranded in short pitch lengths over a centre element for high tensile stresses.

4

Core Identification

 Cores Black with white numerals, one core green­ yellow.

1. Core: U/Ll/C/L+  2. Core: V/L2

3. Core: W/L3/D/L-  4. Core: 4/N

5

Outer jacket

Low adhesion oil- resistant mixture on the basis of PVC, adapted to suit

The Requirements in energy chains* Colour :jet black (Similar to RAL 900S).

6

CFRIP

Strip Cables SO% faster! The tear strip in the outer jacket

7

Bending radius

Moved minimum 7,5 x d   Fixed minimum   4 x d

8

Temperature

Moved -5°C to +70°C for use in energy chains. With

>S0.000 cycles  -50c to +70°C following DIN EN 60811 Fixed    -20°c to +70°c


9

V max.

 10m/s, 5m/s

10

Unsupported/ gliding a max

 80m/s'

11

Travel Distance

 Freely suspended travel distances and up to 100m for gliding applications, class 4

12

Torsion

± 90°, with 1m Cable length

13

UV €resistant

Medium

14

Nominal Voltage

600/1000V (Following DIN VDE 02SO)

15

Testing Voltage

4000 V (Following DIN VDE 0281-2)

16

Oil

Oil-resistant ( Following DIN EN S0363-4-1) Class-2

17

Clean Room

Accord ing to ISO Class-2 outer jacket material complies with CFS.10.07 Tested byIPA According to stranded 14644-1

Typical application area:-

- For high load requirements

- Light oil influence

- Preferably Indoor applications but also outdoor ones at temperature > 5 •c

- Freely suspended travel distances and up to 10m for gliding applications

- Storage and retrieval units for high-bay warehouses, machining units/packaging machines, Quick handling, indoor  cranes.
