DATA / COAX Cable

1

Conductor

Flexible fine copper wire, IS 8130 Class-5/ EN600228

2

Core Insulation

HR, FR, TPE, ZHFR

3

No. of Core / Pair

1Pair to 24Pair & 2 Core 37Core

4

Size of conductor

O.Ssq.mm 2.Ssq. mm (std. IS 8130)

5

Core Twisting

Pair (2core each stranded in pairs with short pitch length, each pair also stranded with short pitch length). Core (In case of core, each core twisted in short pitch As per IS std.)

6

Intermediate Layer

 foil taping over the external layer

7

Overall Shield

Bending resistant   braiding made of tinned copper, coverage approx.

55% linear, approx. 80% optical

8

Outer

Low adhesion mixture on basis of PVC, adapted to  suit the requirements.

PVC used, HR, FR, FRLS, ZHFR.

9

Bending Radius

Moved <l0m Travel moved minimum 7,5xd

>l0m travel moved minimum 10xd

10

Temp.

0°C to 85°C

11

Norm voltage

300/500V

12

Testing

2000V (DIN VDE 0281.2)

13

PVC Compund

As per IS 5831

14

Uses of cable

Medium low requirements & v data signal cable.

- Without influence of oil

-Preferably suspended travel distances and up to SOm for gliding applications

- Wood/ stone processing, packaging industry, supply systems,handling Adajusting equipment.

15

Standard

BS5308 II & VDE0293.

Typical application area:-

- For high load requirements

- Light oil influence

- Preferably Indoor applications but also outdoors ones at temperature > 5 Degree C

- Especially for freely suspended and gliding travel distances and up to 100m

- Storage and retrieval units for high- bay warehouse, machining unit/packaging machines
