PUR Fibre Optic Cable

TPE Fibre Optic Cable

1

Fibre  cables

980/1000 fibre with PE isolation

2

Core stranding

POF  fibre  with  stranded  high-tensile  plastic reinforcement

3

Core identification

Core black

4

Outer jacket

low-adhesion mixture on the basis of PUR, adapted to suit the requirements in energy Chains (following DIN VDE 0282 part 10)  Colour: Red lilac (Similar to RAL 4001)

5

Bending radius

Moved minimum 12,5 x d Fixed   minimum 7,5 x d

6

Temperature

Moved -20°C to +60°C Fixed -25°C to 60°C

7

V max.

Om/s,6m/s

8

Unsupported/ gliding a max

20m/s2

9

Travel Distance

Freely suspended travel distances and up to 20m for gliding applications,Class-2

10

UV Resistant

Medium

11

Oil

Oil-resistant ( following DIN EN 50363-10-2) Class-3

Typical application area:-

- For high load requirements Maximum EMC protection

- Almost unlimited resistance to oil Preferably indoor application

- Freely suspended travel distances and up to 20m for gliding applications Wood/ stone  processing, packaging industry, supply system, handling, adjusting equipment


1

Fibre  cables

20/125 µm, 62,5/125 µm special fixed wire elements with aramide strain relief

2

Core stranding

FOC core stranded with high-tensile aramide dampers with especially short pitch length.

3

Core identification

FOC- Cores :orange or blue, with black numerals

4

Outer jacket

Low-adhesion oil-resistant mixture on the basis of PVC, adapted to suit the requirements in Energy Chains(following DIN VDE Colour: Red lilac (Similar to RAL 4001)

5

Bending radius

Moved minimum 7,5 x d Fixed   minimum 5 x d

6

Temperature

Moved -C to +70°C Fixed  -20°C to 70°C

7

V max.

3m/s, 2m/s

8

Unsupported/ gliding a max

20m/s2

9

Travel Distance

Freely suspended travel distances and up to 20m for gliding applications,Class-2

11

Oil

Oil-resistant ( following DIN EN 50363-4-1) Class-2

Typical application area:-

- For high load requirements

- Light oil influence

- Preferably indoor application , but also outdoor ones at temperature > C

- Freely suspended travel distances and up to Om for gliding applications

- Storage and retrieval units for high-bay warehouses, machining units/ packaging machines, quick handling, indoor   cranes, printer


View / Download
